Product part number:681-ANR-01-50
SMA right angle crimp male
  • Low return loss by measurement.

  • High performance with operation.

  • High quality for various applications.



Product SMA right angle crimp male connector
Frequency 0~12.4GHz for flexible cable
0~18GHz for semi-rigid cable
Impedance 50ohm
Body Brass
Center contact male: Brass / female: Beryllium copper
Insulators PTFE
V.S.W.R straight 1.3max / R.A 1.5max
Insulator resistance >5000 Megohms
